USB Capture HDMI Gen2 USB 3.0 Video Capture Device

Magewell

Supports the Latest USB Capture Utility Software for Easier Capture Settings

What is Video & Audio Capture?
Video & audio capture refers to recording both video and sound and saving them as digital format files. Capture devices are categorized into software compression (soft compression) and hardware compression (hard compression). The difference lies in processing: soft compression relies entirely on the computer's CPU, while hard compression uses a built-in chipset, significantly reducing CPU load and improving capture performance.

● Desktop computers can use software compression capture cards.
● Laptops can use USB-based software compression capture devices.
● Standalone recording devices with hardware compression can operate independently without a computer.

Product Features

USB 3.0 Interface

One HDMI Input Port

Driver-Free Installation

Highest supported resolution

Supports Multiple Operating Systems

Allows Multiple Simultaneous Captures on a Single Computer

Product Introduction

Specification Table

File Download

UVC Driver-Free, No OS Compatibility Issues

Compatible with multiple USB 3.0 chipsets (Intel, Renesas, ASMedia, Fresco Logic)
Supports Windows 7 / 8 / 8.1 / 10, Linux Kernel 2.6.38+, and Mac OS X 10.8+

Full Standard API Support for High Software Compatibility

Powerful Performance & Rich Features

Supports multiple capture devices running simultaneously on one machine
Maximum Video Input Resolution: 1920x1200p60 (CVT-RB)
Maximum Video Output Resolution (YUY2 Format): 1920x1200p60
Processing handled by USB Capture series hardware, reducing CPU load
Video Processing Includes:
Resolution, frame rate, and audio sampling rate conversion
Adjustable brightness, contrast, hue, and saturation
Output Format Support: 4:4:4, 4:2:2, YUV, RGB, 8-bit

Easy to Use & Quick Installation

True Plug-and-Play (No driver installation required for Windows, Linux, and macOS)
Automatic Input Detection & Adjustment:
Automatically detects input video format and scales it to the specified resolution and frame rate
Automatically detects input audio format and converts it to 48 KHz PCM stereo

Reliable & Stable Performance

Built-in 64MB DDR2 Memory:
Provides effective video buffering and USB data flow control
Prevents frame drops or errors due to USB bandwidth congestion
Tested for 7 Days x 24 Hours under continuous high/low temperature conditions (0–50°C)

Bundled Software

USB Capture Utility for advanced controls, including:

Resolution and frame rate settings
Color space conversion
Vertical/horizontal flipping
EDID information retrieval

Software Compatibility Test List

Windows	Linux	Mac OS X
Amcap	Adobe Connect	Adobe Flash Media Live Encoder
Adobe Flash Media Live Encoder	Google Plug Hangouts	Adobe Connect
Adobe Connect	VirtualDub	Google Plug Hangouts
Camtasia Studio	Video Stitch	Gotomeeting
Discover Video Multimedia Encoder	VLC(VideoLAN Client)	OBS (Open Broadcaster Software)
Discover Video Streamsie	OBS (Open Broadcaster Software)	QuickTime Broadcaster
Google Plus Hangouts	Zoom.us	QuickTime Player
Gotomeeting		Resolume
Graphedit		Skype
Livestream		Streambox
Microsoft Lync		Video Stitch
OBS (Open Broadcaster Software)		VirtualDub
Quicktime Player		VLC
Real Producer Plus		VMix
Resolume		Wirecast
Skype		Discover Video Streamsie
Streambox		Zoom.us
Streamstar
Vidblaster
Video Stitch
Vidyo
VirtualDub
VLC
Vmix
Watchout
Windows Media Encoder
Wirecast
XSplit Broadcaster
XSplit Gamecaster
Zoom.us

Product Application

Capture Device Series Comparison Table

Product List

USB Capture HDMI Gen2 ×1

USB 3.0 Cable ×1

※The product specifications and accessories mentioned in the user manual are for reference only. Any changes will not be notified in advance. UPMOST reserves the right to modify product design, accessories, and drivers.

Specification

Please drag left and right to view the specification table

Specifications

Hardware Ports

USB Interface

Computer Connection Port

Video Input Ports

HDMI Video Input

HDMI Audio Input

Video Standards

HDMI Input Format

Output Format

Data Transfer Rate

Output Color Format

Video Processing

Color Format Conversion

Image Scaling

Image Adjustment

System Requirements

Operating System

Supported Software

Supported Development Interface

Hardware Specifications

Dimensions

Power Consumption

Operating Temperature Range

Specifications

Content

Hardware Ports

USB Interface

Compliant with UVC (USB Video Class) and UAC (USB Audio Class) standards

Computer Connection Port

USB 3.0 (300~350MB/s transmission bandwidth)
※ Recommended to use USB 3.0 for optimal resolution and image quality
USB 2.0 (40MB/s transmission bandwidth)

Video Input Ports

One HDMI port

HDMI Video Input

One 1080p @60 signal

HDMI Audio Input

One LPCM embedded audio

Video Standards

HDMI Input Format

Compliant with HDMI 1.4a standard, supporting up to 1080p @60Hz 8-bit (RGB, YUV)

Output Format

Resolutions:
640×360 / 640×480 / 720×480 / 720×576 / 768×576 / 800×600 / 856×480 / 960×540 / 1024×576 / 1024×768 / 1280×720 / 1280×800 / 1280×960 / 1280×1024 / 1368×768 / 1440×900 / 1600×1200 / 1680×1050 / 1920×1080 / 1920×1200

Frame Rates (fps):
25 / 29.97 / 30 / 50 / 59.94 / 60

Data Transfer Rate

165MHz

Output Color Format

YUV 4:2:2（YUY2）/ RGB 4:4:4 (RGB24)

Video Processing

Color Format Conversion

Hardware Color Conversion

Image Scaling

Hardware Scaling Processing

Image Adjustment

Brightness, Contrast, Hue, Saturation Adjustments

System Requirements

Operating System

Windows 7 / 8 / 8.1 / 10 /Server 2008 R2 (32及64位元)
Linux (Kernel version 2.6.38 以上)
Mac OS X (10.8 and above)

Supported Software

Windows Media Encoder (Windows)
Adobe Flash Media Live Encoder (Windows, Mac OS X)
Real Producer Plus (Windows)
VLC (Windows, Mac OS X, Linux)
QuickTime Broadcaster (Mac OS X)
QuickTime Player (Mac OS X)
Wirecast (Windows, Mac OS X), etc.

Supported Development Interface

Hardware Specifications

Dimensions

84.25(L) × 42.8(W) × 12.6(H) mm

Power Consumption

<= 2.5W

Operating Temperature Range

0~50 ℃

File Download

Date

Type

Operating System

Description

File Download

2017.04.19

Product Catalog

Details

0.9MB

PDF
